MAISON T SP
Maison T SP Gearless is the ideal home lift solution for rated loads up to 400 Kg. It is equipped with a premium quality gearless motor and a state of the art inverter which enables outstanding ride quality combined with noise elimination and low energy consumption.
Maison T SP is especially designed to achieve efficient use of space inside the shaft as well as ease of installation and maintenance.
Why Choose MAISON T SP?
Premium quality gearless motor
State of the art inverter
Narrow controller suitable for installation in door frame
Very low energy consumption
Noise and vibration elimination
Ease of installation and maintenance
Rated output consumption 1,1 Kw
Fine selection of design options
EC Type Examination Certificate according to Machinery Directive 2006/42/EC
Technical Specifications
Rated Load | 320kg | 400kg |
---|---|---|
Max Travel (m) | 15 | 15 |
Max Number of Stops | 6 | 6 |
Min Pit Depth (mm) | 250 | 250 |
Min Headroom (mm) | 2600 | 2600 |
Speed (m/s) | 0.30 – 0.40 | 0.30 – 0.40 |
Car Dimensions (mm) | 1000 x 1250 | 1000 x 1250 |
Power Supply | Single Phase | Single Phase |
Motor Supply | 1.1 Kw | 1.1 Kw |
Complies with | EN81.41 – GB 21739-2008 | |
Accessibility | |
